| Applicable Material | | Steel | Stainless Steel | | Min D.O.C. | 7 mm |
| Application | | Ext. Tangential 75° Approach | | Depth of Cut Maximum (APMX) | 35 mm |
| Insert Style | LOMX | Min. Turning Feed (ft(min)) | 1 mm/rev |
| Corner Radius (RE) | 2.4 mm | Max. Turning Feed (ft(max)) | 2 mm/rev |
| Insert Size | 402224 | Clearance Angle Major (AN) | 0 Degrees |
| Cutting Edge Length (L) | 40.3 mm | Cutting Direction (HAND) | Neutral |
| Insert Thickness (S) | 22.6 mm | Chip Breaker Type | H6P |
| Cutting Edge Material | Carbide | Measurement Type | Metric |
| Coating | TiCN+Al2O3+TiN | Body Material | Carbide |
| Grade | IC8250 | Unit | M |
| Tool Type | Turn Negative Inserts |
Product Features
| Family Description | Tangential inserts with 4 cutting edges for high metal removal of up to 35 mm D.O.C. on steel | FamilyName | LOMX-H6P |
| COO | Israel | BrandName | Iscar |
Shipping Info
Weight per item
0.1690
Name
Turning Indexable Inserts
FamilyName
LOMX-H6P
BrandName
Iscar
