| Usable Length (LU) | 8.62 mm | Coolant Supply Property (CSP) | Coolant Thru |
| Application | | Drilling | | Measurement Type | Metric |
| Connection Diameter Machine Side (DCONMS) | 7.6 mm | Master Insert Identification (MIID) | ICP 040 |
| Insert Seat Size Code (SSC) | 4.0 | Point Length (PL) | 0.62 mm |
| Cutting Diameter Minimum (DCN) | 4 mm | Body Material | Steel |
| Cutting Diameter Maximum (DCX) | 4.49 mm | Shank Diameter Tolerance (TCDMM) | $$$$ |
| Protruding Length (LPR) | 22 mm | Unit | M |
| Overall Length (OAL) | 28.75 mm |
Product Features
| Family Description | Modular SUMOCHAM drills are dedicated for Multi-Spindle and Swiss-Type machines with a MULTI-MASTER connection for easy adaptation and set up. | COO | Israel |
| Remarks | Do not mount smaller drilling heads other than the specified range of the drill body |
