| Applicable Material | | Aluminum / Non-Ferrous Materials | | Cutting Edge Material | Carbide |
| Application | | Facing | Helical Interpolation | Plunging & Recessing | Profiling | Rampdown | Shouldering | Slotting | | Tool Type | Single sided Inserts |
| Corner Radius (RE) | 8 mm | Minimum Feed per Tooth (fz(min)) | 0.15 mm/tooth |
| Inscribed Circle Diameter (IC) | 16 mm | Number of Cutting Edges | 8 |
| Insert Thickness (S) | 5 mm | Measurement Type | Metric |
| Coating | Uncoated | Body Material | Carbide |
| Grade | IC28 | Unit | M |
| Maximum Feed per Tooth (fz(max)) | 0.4 mm/tooth |
Product Features
| Family Description | Round positive rake milling inserts with a bottom cylinder for improved clamping. RCMT - Positive rake and reinforced cutting edge, RCCT - Positive rake and sharp cutting edge, both used mainly on stainless steel. | FamilyName | RCMT/RCCT-MO |
| Remarks | RCMT - Positive rake and reinforced cutting edge RCCT - Positive rake and sharp cutting edge Both used mainly on stainless steel | BrandName | Iscar |
| COO | Israel |
Shipping Info
Weight per item
0.0137
Name
Milling Indexable Inserts
FamilyName
RCMT/RCCT-MO
BrandName
Iscar
